Power Supply: −17.5 VDC to −26 VDC

Sensitivity: Less than 2 mV change per gap variation

Output Resistance: 50 Ω

Recommended Gap Setting for Radial Vibration: −9 VDC

Standard System Cable Length: 1 m or 5 m

Sensitivity / Output Scale: 7.87 V/mm (200 mV/mil) ±5%

Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical

Field Wiring: 0.2 to 1.5 mm² (16 to 24 AWG)

Linear Range: 2 mm (80 mils)

The system provides an output voltage that is directlyproportional to the distance between the probe tip and theobserved conductive surface and can measure both static(position)and dynamic (vibration)values. The system'sprimary applications are vibration and positionmeasurements on fluid-film bearing machines, as well asKeyphasor reference and speed measurements3.

Frequently asked questions：

Q:Is this product brand new?

A:Yes, 330101-00-15-15-02-05 is brand new, original, unused, and factory sealed

Q:Do you have it in stock?

A:Yes, right now we have330101-00-15-15-02-05 in stock ready for shipment, we can support video inspection.

Q:What payment mothod we used?

A:We usually use T/T (Telegraphic Transfer).

Q:How do I get the price of 330101-00-15-15-02-05?

A:Please contact our Sales Manager Ms. Lisa for a discount exclusive quote, Email sales7@amikon.cn/WhatsApp : +86 18965423501.

Contact Lisa to obtain the additional discount：
