Output Resistance: 50 Ω

Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft), typical

Minimum Target Size: 15.2 mm (0.6 in) diameter (flat target)

Minimum Recommended Target Size: 50.8 mm (2 in)

Recommended Target Size: 76.2 mm (3 in)

Probe Tip Material: Polyphenylene sulfide (PPS)

Probe Case Material: AISI 303 or 304 stainless steel (SST)

Minimum Cable Bend Radius: 25.4 mm (1.0 in)

The system provides an output voltage that is directly proportional to the distance between the probe tip and the observed conductive surface and can measure both static (position) and dynamic (vibration) values. The system’s primary applications are vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements3. The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute’s (API) 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. All 3300 XL 8 mm proximity transducer systems provide this level of performance and support complete interchangeability of probes, extension cables, and Proximitor sensors, eliminating the need to match or bench calibrate individual components
