Description：

The 3300 XL Shaft Micrometer is primarily used to check theoutput signal of a Proximitor Sensor when viewing the rotorshaft or a reciprocating compressor piston rod. A strapattaches to a mounting base, is wrapped around the target,and is tightened to hold the mounting base firmly in position.

A spindle micrometer verifies the Proximitor Sensor outputsignal. A probe mounting adapter holds the probe in themounting base, and the micrometer moves the probe toward and away from the target in calibrated increments. The output from the Proximitor Sensor is recorded using a voltmeter.

When using the 3300 XL Shaft Micrometer togenerate an output curve for programming aRod Drop Monitor on a reciprocatingcompressor, use the buffered output signal onthe front of the rod drop monitor rather thanthe output signal on the Proximitor Sensor. Thisis because the Rod Drop Monitor isprogrammed by the user based on the signalat the monitor. This signal will vary from theoutput signal on the Proximitor Sensor if youare using intrinsic safety barriers.

Specification：

Frequently asked questions

Q1: What is the Bently Nevada 330186-02 3300 XL Shaft Micrometer used for?

A1:The Bently Nevada 330186-02 3300 XL Shaft Micrometer is a precision measuring tool used for shaft positioning, probe gap verification, and calibration of machinery monitoring systems. It helps ensure accurate setup and maintenance of proximity probe installations.

Q2: What does Scale Units Option 02 indicate?

A2:The 330186-02 Scale Units Option 02 indicates that the micrometer uses metric units and provides measurements within a 0–25 mm range.

Q3: What is the measurement range of the 330186-02 micrometer?

A3:The 330186-02 micrometer offers a measurement range of 0 to 25 mm, making it suitable for precision shaft and probe alignment applications.

Q4: What is the resolution of the 330186-02 Shaft Micrometer?

A4:The 330186-02 micrometer provides a resolution of 0.01 mm, allowing users to make accurate and repeatable measurements.

Product Applications

Oil and Gas Chemical Plants: Oil refineries, natural gas liquefaction (LNG) plants, ethylene plants, and large-scale fertilizer plants.

Coal and Nuclear Power Plants: Large energy plants equipped with gas turbines and large steam turbine generator sets.

Large Steel and Metallurgical Plants: Blast furnace blower rooms and power workshops for large rolling mills.

Air Separation and Oxygen Production Plants: Industrial gas plants equipped with large centrifugal or axial flow air compressors.

Hydropower and Pumped Storage Power Stations: Maintenance of thrust bearings and axial displacement monitoring for large hydroelectric generator sets.
