330705-02-18-10-02-00   Reverse Mount Probes

Dimensions ：20.4x22.2x3.7cm

Weight：0.1kg

Reverse Mount Probes manufactured by Bently Nevada. It is used inProximity Transducer System. The 3.94 V/mm (100 mV/mil) output of the Transducer System is designed for non-contact vibration and displacement measurements on fluid film bearing devices.

Full Description:  Bently Nevada 330705-02-18-10-02-00 Proximity Transducer

The 3300 XL 11 mm Proximity Transducer System has a 3.94 V/mm (100 mV/mil)

output for non-contacting vibration and displacement measurements

on fluid film bearing machines.

Features：

The 3300 XL 11 mm probe is available in a variety of probe case configurations, including armored and unarmored probe threads. The reverse mount 3300 XL 11 mm probe is available with either 3/8 -24 or M10 X 1 threads as standard.

All transducer system components use gold-plated brass ClickLocTM connectors. ClickLoc connections secure the connection, preventing it from getting loose.

The innovative TipLocTM molding procedure creates a strong attachment between the probe tip and body. Our proprietary CableLoc design secures the probe cable to the probe tip and delivers 330 N (75 lb) pull strength.
