Manufacturer : Bently Nevada

Model: 330709-000-040-10-02-00

Product Type : Proximity Probes

Made in U.S.A

Can add on Certificate Of Origin

Unthreaded Length Option : 000 = 0 mm

Overall Case Length Option : 040 = 40mm

Total Length Option : 10 = 1.0 metre (3.3 feet)

Connector and Cable-Type Option : 02 = Miniature coaxial ClickLoc connector, standard cable

Agency Approval Option : 00 = Not required

Shipping Weight : 2 Kg

The 3300 XL 11 mm Proximity Transducer System has a 3.94 V/mm (100 mV/mil) output for non-contacting vibration and displacement measurements on fluid film bearing machines. The large 11 mm tip enables this transducer system to have a longer linear range compared to the standard 3300 XL 8 mm Transducer System. It is primarily used in the following applications where the longer linear range is necessary:

Axial (thrust) position measurements

Ramp differential expansion measurements on steam turbines

Rod position or rod drop measurements on reciprocating compressors

Tachometer and zero speed measurements

Phase reference (Keyphasor) signals

Frequently Asked Questions

Q1: What is the Bently Nevada 330709-000-040-10-02-00?

A1: It is a proximity probe designed for non-contact measurement of shaft vibration and displacement in rotating machinery monitoring systems.

Q2: What does the “040” option represent?

A2: “040” indicates an overall case length of 40 mm.

Q3: What does the “10” option represent?

A3: “10” specifies a total cable length of 1.0 meter (approximately 3.3 feet).

Q4: What is the 330709-000-040-10-02-00 main function of this proximity probe?

A4: It measures shaft position and vibration without physical contact, enabling accurate condition monitoring and machinery protection.

Q5: Where is the 330709-000-040-10-02-00 probe typically used?

A5: It is commonly used in turbines, compressors, pumps, and motors across industries such as oil & gas, power generation, and manufacturing.

Product Applications

Petroleum and chemical plants: Vibration monitoring for turbine compressors, fans, and gearboxes.

Power plants (thermal power/ nuclear power/water power): Bearing displacement and vibration monitoring for steam turbines, generators, and water turbines.

Metallurgical industry: Shaft condition monitoring for large blowers and furnace drive equipment.
