The 3300 XL NSv Transducer System design allows it toreplace both the 3300 RAM Transducer Systems and the3000-series or 7000-series 190 Transducer System. Upgradesfrom the 3300 RAM system to the 3300 XL NSv system mayuse the existing probe, extension cable, and monitoring system with 3300 XL NSv ProximitorSensor. Upgrades from the 3000-series or7000-series Transducer System must replacethe probe, extension cable, and ProximitorSensor with NSv components.

The 3300 XL NSv Transducer System has anAverage Scale Factor of 7.87 V/mm (200mV/mil), which is the most common output foreddy current transducers. Its enhanced side-view and small target characteristics give it ashorter linear range than the Bently Nevada3300 XL-series 5 and 8 mm Transducer System.The 1.5 mm (60 mils) of linear range exceedsthe linear range of the 3000-series 190Transducer System.

Frequently asked questions：

Q: When should I use a 3300 NSv™ probe instead of a standard 3300 XL 8mm probe?

A: Use the 330901 NSv™ when your target diameter is smaller than 13mm (0.5 in) or when the probe must be installed in a very narrow counterbore. Standard 8mm probes require a larger "view" and will provide inaccurate data if the target is too small.

Q: What is the significance of the "05" Approval Option?

A: The "05" code indicates multiple global hazardous area certifications, including CSA, ATEX, and IECEx. This makes the probe suitable for use in explosive atmospheres common in oil and gas refineries.

Q: Is the 330901-00-24-05-02-05 compatible with 3300 XL extension cables?

A: No. The 3300 NSv™ system uses its own specific extension cables and Proximitor® sensors. Mixing NSv™ probes with 3300 XL components will result in incorrect calibration and measurement errors.

Q: What is the benefit of the 0.5m cable length (Option 05)?

A: Short integral cables are preferred for installations where the junction box is mounted very close to the machine casing, reducing cable clutter and signal noise in high-vibration environments.

Q: Can this probe be used for Fluid-Film Bearing machines?

A: Yes, it is the primary choice for small-bore fluid-film bearings where space for sensor mounting is extremely limited.

Product Applications

Electric power industry: Monitoring radial vibration and axial displacement of small rotating equipment such as steam turbines and feedwater pumps.

Petroleum and chemical industry: Mechanical protection and condition monitoring for key centrifuges, small motors and gearboxes.

Heavy industry manufacturing: Monitoring precision spindles on production lines to prevent unexpected shutdowns due to wear or imbalance.

Metallurgical industry: Monitoring mechanical power systems related to the melting process.
