Brand/Manufature:
Bently NevadaProduct Origin:
USALead Time:
IN STOCKCondition:
Brand New And 100% OriginalCertificate:
Coo|
Brand Name |
Bently Nevada |
|
Model Number |
330903-00-05-10-02-05/CN |
|
Type |
Sensor Proximity Probe Cable |
|
Extension Cable DC Resistance |
Center conductor: 0.220 Ω/m (0.067 Ω/ft) |
|
Shield: 0.066 Ω/m (0.020 Ω/ft) |
|
|
Extension Cable Capacitance |
69.9 pF/m (21.3 pF/ft) typical |
|
Recommended Gap Setting |
1.0 mm (40 mils) |
|
Deviation from Best Fit Straight Line (DSL) |
Less than ±0.06 mm (±2.3 mils) |
|
Output Resistance |
50 Ω |
|
Connector Material |
Gold-plated brass |
|
Probe Tip Material |
Polyphenylene sulfide (PPS) |
|
Probe Case Material |
AISI 304 stainless steel (SST) |
|
Recommended Torque |
Finger tight |
|
Maximum Torque |
0.56 N•m (5 in•lb) |
The 3300 NSv probe and extension cable are mechanically and electrically compatible and interchangeable with Bently Nevada’s previous 3300 RAM proximity probe and extension cable. The NSv probe has increased chemical resistance compared to the 3300 RAM probe, which makes it suitable for use in many process compressor applications. Additionally, the side-view characteristics of the 3300 NSv probe are superior to those of the 3000-series 190 probe, especially when gapping the 3300 NSv probe at the same distance from the probe target. This feature provides improved performance and reliability in challenging environments.
The 3300 XL NSv Proximitor Sensor shares many features with the 3300 XL 8 mm Proximitor Sensor. Its thin design enables flexible mounting options, such as high-density DIN-rail installations or more traditional panel mount configurations. The sensor also boasts improved RFI/EMI immunity, which ensures that the 3300 XL NSv Proximitor Sensor meets European CE mark approvals without requiring special mounting considerations. This enhanced RFI immunity helps protect the system from interference caused by nearby high-frequency radio signals, ensuring reliable performance. Additionally, the SpringLoc terminal strips on the Proximitor Sensor require no special installation tools, allowing for faster and more robust field wiring connections.
