Brand/Manufature:
Bently NevadaProduct Origin:
USALead Time:
IN STOCKCondition:
Brand New And 100% OriginalCertificate:
Coo|
Specification |
Details |
|
Manufacturer |
Bently Nevada |
|
Model |
330903-00-10-10-02-05 |
|
Type |
Proximity Probes |
|
Recommended Gap Setting |
1.0 mm (40 mils) |
|
Deviation from Best Fit Straight Line (DSL) |
Less than ±0.06 mm (±2.3 mils) |
|
Proximitor Sensor Material |
A380 aluminum |
|
System Length |
5 or 7 meters including extension cable |
|
Recommended Torque |
Finger tight |
|
Maximum Torque |
0.56 N•m (5 in•lb) |
|
Probe Weight |
Approximately 14 to 150 g (0.5 to 5.3 oz) |
|
Extension Cable Weight |
45 g/m (0.5 oz/ft) |
|
Armored Extension Cable Weight |
64 g/m (0.7 oz/ft) |
|
Proximitor Sensor Weight |
255 g (9 oz) |
The 3300 NSv probe is available in various probe case configurations, including armored and unarmored versions with thread sizes of 1/4-28, 3⁄8-24, M8X1, and M10X1. The reverse mount 3300 NSv probe is standard with either 3⁄8-24 or M10X1 threads. All components of the transducer system are equipped with gold-plated brass ClickLoc connectors. These connectors lock into place, preventing the connection from loosening. The patented TipLoc molding method ensures a robust bond between the probe tip and the probe body. Bently Nevada's patented CableLoc design offers 220 N (50 lb) of pull strength, securely attaching the probe cable to the probe tip.
Connector protectors are recommended for use on the probe-to-extension cable connection as well as on the cable-to-Proximitor Sensor connection. These protectors help prevent most liquids from entering the ClickLoc connectors and adversely affecting the electrical signal.
Notes:
Proximitor Sensors are supplied by default from the factory calibrated to AISI 4140 steel. Calibration to other target materials is available upon request.
Silicone tape is also provided with each 3300 NSv extension cable and can be used instead of connector protectors. However, silicone tape is not recommended for applications where the probe-to-extension cable connection will be exposed to turbine oil.
+86 18030132585
+86 18030132585
sales16@amikon.cn
ZXD18030132585
1)100% full New! - Original Factory Seal !
2)We have DHL,UPS,TNT ，customers can also use their own freight forwarders.
3)Package: Original packing with cartons.
4)Delivery time: Shipped in 3 days after payment.
5)Strict packaging to ensure safe arrival at destination.
Why choose us?
1.100% original product, 100% quality assurance and the more competitive price.
We send you a new product asking zero cent!
2.Thoughful service
Professional after-sales service.
3.Quick Shipping
We have large quantities of inventories, can ship immediately.
Amikon sells new and surplus products and develops channels to purchase such products.
This site is not approved or endorsed by any of the listed manufacturers or trademarks.
Amikon is not an authorized distributor, dealer or representative of the products displayed on this site.
All product names, trademarks, brands and logos used on this site are the property of their respective owners.
The description, illustration or sale of products under these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
