Brand/Manufature:
Bently NevadaProduct Origin:
USALead Time:
IN STOCKCondition:
Brand New And 100% OriginalCertificate:
Coo|
Manufacturer: Bently Nevada |
|
Product Number: 330903-00-10-50-02-00 |
|
Type: 3300 NSv Proximity Probes |
|
A: Unthreaded Length Option |
|
Order in increments of 10 mm. |
|
Length configuration: |
|
Maximum unthreaded length: 230 mm |
|
Minimum unthreaded length: 0 mm |
|
Example: 06 = 60 mm |
|
Probe: Approximately 14 to 150 g (0.5 to 5.3 oz) |
|
Extension Cable: 45 g/m (0.5 oz/ft) |
|
Armored Extension Cable: 64 g/m (0.7 oz/ft) |
|
Proximitor Sensor: 255 g (9 oz) |
The 3300 NSv probe comes in varying probe case configurations, including armored and unarmored 1/4-28, 3⁄8-24, M8X1, and M10X1 probe threads. The reverse mount 3300 NSv probe comes standard with either 3⁄8-24 or M10X1 threads. All components of the transducer system have gold-plated brass ClickLoc connectors. ClickLoc connectors lock into place and prevent the connection from loosening. The patented TipLoc molding method provides a robust bond between the probe tip and the probe body. Bently Nevada’s patented CableLoc design provides 220 N (50 lb) of pull strength and securely attaches the probe cable to the probe tip. Connector protectors are recommended for use on the probe-to-extension cable connection, as well as on the cable-to-Proximitor Sensor connection.
Frequently Asked Questions
Q1: What is the 330903-00-10-50-02-00 used for?
A: This 3300 NSv proximity probe is used for non-contact vibration, displacement, and shaft position monitoring in rotating machinery.
Q2: What is the 330903-00-10-50-02-00 measurement range?
A: The probe provides a linear measurement range of approximately 1.5 mm (60 mils).
Q3: What is the 330903-00-10-50-02-00 scale factor?
A: The scale factor is 7.87 V/mm (200 mV/mil), ensuring precise displacement measurement.
Q4: What is the 330903-00-10-50-02-00 recommended operating gap?
A: The recommended gap is ~1.0 mm (40 mils) for optimal performance.
Q5: What is the 330903-00-10-50-02-00 frequency response?
A: It supports a frequency range of 0 to 10 kHz, suitable for most industrial vibration monitoring applications.
Product Applications
Oil and Gas: Monitoring of shaft displacement and shaft vibration for key compressors, pumps, and electric motors to ensure the safe operation of high-pressure equipment.
Power Generation and Electricity: Monitoring of the rotor positions of steam turbines, hydro turbines, and generators to prevent damage to the units due to bearing wear.
Mechanical Manufacturing: Transient monitoring of compact fans, gearboxes, and turbine machinery.
Specific technical advantages:
Space optimization: Specifically designed for "near-surface" applications with extremely limited space (such as small turbines).
High precision: Offers a 1.5mm linear measurement range and high sensitivity.
Compatibility: Directly compatible with the Bently 3300 RAM monitoring system, making it an ideal replacement solution for older proximity probes.
