The 3300 XL NSv Proximity Transducer system is intended for use with centrifugal air compressors, refrigeration compressors, process gas compressors, and other machines with tight installation requirements.  The 3300 XL NSv Proximity Transducer System consists of:

a 3300 NSv probe

a 3300 NSv extension cable

a 3300 XL NSv Proximitor Sensor(1)

The primary uses for the 3300 XL NSv Transducer System are for areas where counter bore, sideview, or rearview restrictions limit the use of standard Bently Nevada 3300 and 3300 XL 5 and 8 mm Transducer Systems.  It is also ideal for small target applications, such as measuring radial vibration on shafts smaller than 51 mm (2 in) or axial position on flat targets smaller than 15 mm (0.6 in).  It is primarily used in the following applications on fluid-filmed bearing machines where a small shaft or reduced side-view is present:

Radial vibration and radial position measurements

Axial (thrust) position measurements

Tachometer and zero speed measurements

Phase reference (Keyphasor signals)

Frequently Asked Questions

1. What is the overall case length of the Bently Nevada 330904-00-23-10-02-00?

This 330904-00-23-10-02-00 model features Overall Case Length Option 23, corresponding to an overall case length of 230 mm, making it suitable for a wide range of industrial machinery monitoring applications.

2. What is the 330904-00-23-10-02-00 total probe length?

The 330904-00-23-10-02-00 probe uses Total Length Option 10, providing a total probe length of 1.0 meter (39 inches) for standard industrial installations.

3. What is the 330904-00-23-10-02-00 output resistance of this proximity probe?

The 330904-00-23-10-02-00 has an output resistance of 50 Ω, ensuring stable signal transmission and compatibility with the associated proximity transducer system.

4. What is the supply sensitivity of the 330904-00-23-10-02-00 probe?

The 330904-00-23-10-02-00 probe features a supply sensitivity of less than 2 mV change, helping maintain stable output even when minor power supply fluctuations occur.

Product Applications

Oil and Gas (Refineries, LNG Terminals, Oil Production Platforms)

Power and Energy (Small and Medium-Sized Steam Turbines, Hydropower Equipment, and Auxiliary Pumps)

Chemicals and Heavy Chemicals (Various High-Pressure Gas Circulation Units)

Large-Scale Industrial Manufacturing (Factory Power Workshops, Air Compressor Stations, Large-Scale Refrigeration Stations)
