Model Number: 330910-00-06-05-02-05

Output Resistance: 50 Ω

Recommended Gap Setting: 1.0 mm (40 mils)

Extension Cable DC Resistance:

Center conductor: 0.220 Ω/m (0.067 Ω/ft)

Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft), typical

Deviation from Best Fit Straight Line (DSL): Less than ±0.06 mm (±2.3 mils)

Minimum Target Size (Flat Target): 8.9 mm (0.35 in) diameter

Counterbore Minimum: 9.5 mm (0.375 in)

System Length Options: 5 or 7 meters (including probe and extension cable)

Proximitor Sensor Material: A380 aluminum

Probe Tip Material: Polyphenylene sulfide (PPS)

Probe Case Material: AISI 304 stainless steel (SST)

3300 NSv probes are designed to seal differential pressure between the probe tip and case. The probe sealing material consists of a Viton O-ring. Probes are not pressure tested prior to shipment. Contact our custom design department if you require a test of the pressure seal for your application.The 3300 XL NSv Proximity Transducer system is intended for use with centrifugal air compressors, refrigeration compressors, process gas compressors, and other machines with tight in stallation requirements.The 1.5 mm (60 mils) of linear range exceeds the linear range of the 3000-series 190 Transducer System.The 3300 XL NSv Proximitor Sensor has similar features to those found in the 3300 XL 8 mm Proximitor Sensor.This RFI immunity also prevents nearby high frequency radio signals from adversely affecting the transducer system. The reverse mount 3300 NSvprobe comes standard with either 3⁄8-24 or M10X1 threads. All components of the transducer system have gold-plated brassClickLoc connectors.
