Description：

Use the 3500 System rack to mount all 3500 monitor modulesand power supplies. The rack allows you to place 3500modules near one another, enabling them to easilycommunicate, and to mount power supplies necessary todistribute power to each module.

3500 racks are available in two sizes:

Full-size rack. 19-inch ElA rack with 14 available module slots.

Mini-rack. 12-inch rack with seven available module slots.

You can order 3500 racks in three formats:

Panel mount. This rack format mounts to rectangular cut-outs in panels, and secures to the panel using clampssupplied with the rack. Wiring connections and I/O modulesare accessible from the rear of the rack.

Rack mount. This rack format mounts the 3500 Rack on 19-inch EIA rails. Wiring connections and I/O modules areaccessible from the rear of the rack.

Bulkhead mount. This rack format mounts the rack against awall or panel when it is not possible to access the rear of therack. Wiring connections and I/O modules are accessiblefrom the front of the rack. The 3500/05 Mini-Rack is notavailable in this format.

The power supplies and rack interface module must occupythe far-left rack positions. The remaining 14 rack positions(seven rack positions for the mini-rack) are available for anycombination of modules.

Specification：

Frequently asked questions

Q1: What is the Bently Nevada 3500/05-02-04-01-00-00 System Rack?

A1: It is a 3500 Series machinery protection system rack designed to house monitoring and protection modules for industrial rotating equipment applications.

Q2: What does rack size option “02” indicate?

A2: The “02” option specifies a 12-inch mini-rack configuration with 7 module slots.

Q3: What does mounting option “04” indicate?

A3: The “04” option specifies a panel mount configuration for the mini-rack installation.

Q4: What is the 3500/05-02-04-01-00-00 difference between the full-size rack and mini-rack?

A4: The full-size rack is a 19-inch EIA rack with 14 module slots, while the mini-rack is a 12-inch rack with 7 module slots for compact installations.

Q5: What is the 3500/05-02-04-01-00-00 main function of the 3500 system rack?

A5: Its main function is to provide mechanical support, power distribution, and communication integration for 3500 monitoring and protection modules.

Product Applications

Petrochemical (Petroleum and Natural Gas): Oil extraction, refining, ethylene plants, etc.

Chemical Industry: Large compressors, pumps, air separation units.

Power Generation Industry: Steam turbines in thermal power plants, rotating equipment in nuclear power plants, water turbines for hydropower.

Metallurgy Industry: Blast furnace blowers, oxygen compressors.

Heavy Industry/Manufacturing: Turbines, large cooling pumps, gearboxes.
