Description：

The Bently NevadatM 3500/22M Transient Data Interface (TDl)is the interface between the 3500 monitoring system andcompatible software (System 1 Condition Monitoring andDiagnostic software and 3500 System Configurationsoftware). The TDI combines the function of a 3500/20 RackInterface Module (RIM) with the data collection capability of acommunication processor such as TDxnet.

The TDl resides in the slot adjacent to the power supplies of a3500 rack. It interfaces with M series monitors (3500/40M,3500/42M, etc.) to continuously collect steady state andtransient dynamic (waveform) data and pass this datathrough an Ethernet link to the host software. Refer to theCompatibility section at the end of this document for moreinformation.

Specification：

Frequently asked questions

Q1: What is the Bently Nevada 3500/22-01-01-01?

A1: It is a Transient Data Interface (TDI) module used in the 3500 monitoring system to collect, process, and communicate machinery condition and transient data.

Q2: What is the 3500/22-01-01-01 power consumption?

A2: The 3500/22-01-01-01 module consumes approximately 10.5 watts during operation.

Q3: What does the “01” transient data interface type represent?

A3: “01” indicates the standard TDI version, suitable for typical monitoring and data acquisition applications.

Q4: What does the “01” I/O module type represent?

A4: It refers to a 10Base-T / 100Base-TX Ethernet I/O module, enabling network communication with monitoring systems.

Q5: What does the “01” agency approval option indicate?

A5: “01” signifies CSA/NRTL/C certification, ensuring compliance with recognized safety standards.

Product Applications

Oil and gas plants: Online condition monitoring of compressor units, gas turbines, and high-pressure pumps.

Power plants (coal/gas turbine): Vibration analysis and transient data recording (start-up/shutdown data) of steam turbine generator units.

Petrochemical plants: High-power centrifugal compressors, fans, and large pumps.

Metallurgy and petrochemicals: Turbine expanders, critical fans, and air pumps.
