Description：

The IS200JPDHG1A is a PCB component created as a part of the Mark VI system by General Electric.  The Mark VI was released by GE as part of their Speedtronic line for gas and steam turbine management, which began in the 1960s with the release of the Mark I.  The Mark VI is usually powered from a 125Vdc battery system. However, it can be powered from a 120/240vac source, using a power converter with an isolation transformer that rectifies the power to 125Vdc. For gas turbines, a separate power source is required for the ignition transformers with short circuit protection of 20A or less.

The IS200JPDHG1A is a High-Density Power Distribution Card.  This board provides individual protected control power to each I/O pack.  Several IS200JPDHG1A boards can be daisy-chained together using the J1 and J1X connectors; however, when this is done, the input current cannot exceed the rating of the first JPDH J1 plug.  The IS200JPDHG1A can be used in some hazardous locations, including Class 1 Division 2, Class 1 Zone 2, and ATEX. Users must follow UL/ATEX HazLoc requirements for wiring and maintenance.

Specification：

Frequently asked questions

Q1: What is the GE IS200JPDHG1A used for?

A1:The GE IS200JPDHG1A is a Power Distribution Card used in industrial control systems to distribute and manage power for connected modules and field devices, ensuring reliable system operation.

Q2: What is the rated input voltage of the IS200JPDHG1A?

A2:The IS200JPDHG1A card has a rated input voltage of 28 VDC, providing stable power distribution within the control system.

Q3: What output voltage does the IS200JPDHG1A provide?

A3:The IS200JPDHG1A module delivers an output voltage of 28 VDC, ensuring consistent power supply to connected equipment.

Q4: What is the IS200JPDHG1A operating temperature range of this power distribution card?

A4:The IS200JPDHG1A operates within a temperature range of -30°C to +65°C (-22°F to +149°F), making it suitable for demanding industrial environments.

Product Applications

Electricity and Energy: Coal-fired/gas-fired power plants, nuclear power plants, and hydroelectric power facilities.

Oil and Gas: Large-scale oil refineries, natural gas compressor stations, and other hazardous explosion-proof locations (Class I Div 2).

Heavy Manufacturing: Large-scale chemical plants, steel smelters, and other factories with their own power plants or large rotating machinery.
