Description：

The IS200JPDHG1A is a PCB component created as a part of the Mark VI system by General Electric.  The Mark VI was released by GE as part of their Speedtronic line for gas and steam turbine management, which began in the 1960s with the release of the Mark I.  The Mark VI is usually powered from a 125Vdc battery system. However, it can be powered from a 120/240vac source, using a power converter with an isolation transformer that rectifies the power to 125Vdc. For gas turbines, a separate power source is required for the ignition transformers with short circuit protection of 20A or less.

The IS200JPDHG1A is a High-Density Power Distribution Card.  This board provides individual protected control power to each I/O pack.  Several IS200JPDHG1A boards can be daisy-chained together using the J1 and J1X connectors; however, when this is done, the input current cannot exceed the rating of the first JPDH J1 plug.

Specification：

Frequently asked questions

Q1: What is the GE IS200JPDHG1A Power Distribution Card used for?

A: The IS200JPDHG1A is a Power Distribution Card used in GE turbine and industrial control systems.

Q2: What is the rated input voltage of the IS200JPDHG1A?

A: The IS200JPDHG1A module supports a rated input voltage range of 24 VDC to 28 VDC, making it suitable for standard industrial DC power systems.

Q3: What is the maximum output current of the IS200JPDHG1A?

A: The IS200JPDHG1A card can provide a maximum output current of 10 A, allowing it to supply power to multiple connected modules and devices.

Q4: What is the operating temperature range of the IS200JPDHG1A?

A: The IS200JPDHG1A module is designed to operate in temperatures ranging from -30°C to +65°C, making it suitable for demanding industrial environments.

Product Applications

Thermal and gas-fired power plants: Serving as the power and distribution core of the GE Mark VI/VIe system, directly used for the management and protection control of heavy-duty gas turbines and steam turbines.

Oil and gas refineries: Acting as the power distribution hub in compressor control, pipeline pumping stations, and hazardous area monitoring systems in large petrochemical plants.

Large chemical plants: Used in high-risk, uninterrupted production critical process control systems (DCS), providing transient voltage suppression to ensure uninterrupted power supply to the control network.

Steel and metallurgical plants: Applied in blower and large blast furnace control, as well as in high-dust, high-interference heavy industrial environments.
