ABB SDCS-UCM-1C 3ADT220090R0008 External DC Voltage Measurement Board

SDCS-UCM-1C 3ADT220090R0008
SDCS-UCM-1C 3ADT220090R0008
SDCS-UCM-1C 3ADT220090R0008

ABB SDCS-UCM-1C 3ADT220090R0008 External DC Voltage Measurement Board

✉  INQUIRE NOW

ABB · DCS880

SDCS-UCM-1C 3ADT220090R0008

External DC Voltage Measurement Board

MANUFACTURERABB
MODELSDCS-UCM-1C
PART NUMBER3ADT220090R0008
PRODUCT TYPEExternal DC Voltage Measurement Board
SYSTEM FAMILYDCS880
ORDER SUPPORTModel Verification

INDUSTRIAL AUTOMATION SPARE PARTS PARTNER

20 Years of Experience in Industrial Automation Supply

AMIKON supplies industrial automation spare parts to maintenance, engineering and procurement teams worldwide. Our focus includes discontinued and hard-to-find DCS, PLC and TSI components, helping customers identify the correct model, source replacement parts and support urgent maintenance requirements.

Discontinued Parts SourcingModel Identification SupportGlobal Customer SupportIn-Stock Supply Support
  • Item NO.:

    SDCS-UCM-1C 3ADT220090R0008
  • Product Origin:

    Sweden
  • Lead Time:

    IN STOCK
  • Brand/Manufature:

    ABB
  • Product Origin:

    Sweden
  • Lead Time:

    IN STOCK
  • Condition:

    Brand New And 100% Original
  • Certificate:

    Coo

DCS880

SDCS-UCM-1C 3ADT220090R0008

Price and Availability Inquiry

The SDCS-UCM-1C is an external DC-voltage measurement board for DCS880 H1–H5 hardware, using resistor chains to scale motor-armature voltage for the control-board analog input.

Sales SupportDirect specialist contact
QuotationCurrent commercial details
DeliveryDHL · FedEx · UPS

Your AMIKON Contact

LLLisa Lin
WhatsApp+86 18965423501
For faster service, include SDCS-UCM-1C 3ADT220090R0008 and required quantity.

ABB SDCS-UCM-1C 3ADT220090R0008

Technical Specifications

Published technical data for identification, electrical interface, compatibility, installation and service selection.

01Product IdentityExact board identification
ManufacturerABB
Type designationSDCS-UCM-1C
Product ID3ADT220090R0008
Product classExternal DC voltage measurement board
02Electrical InterfacePublished connection path
Positive DC inputX1 to C1
Negative DC inputX2 to D1
Measurement outputX3 to XAI:AI3
Circuit methodTwo resistor chains
03Voltage ConfigurationPublished terminal positions
Up to 400 V DCX1 position 4 / X2 position 4
Up to 500 V DCX1 position 4 / X2 position 4
Up to 600 V DCX1 position 3 / X2 position 3
Safety potentialX1 and X2 at motor DC potential
04Compatibility & PhysicalDCS880 installation data
Drive familyDCS880
Hardware sizesH1–H5
MountingExternal to the converter
Holder outline180 × 70 mm

SDCS-UCM-1C 3ADT220090R0008 Product Support

Frequently Asked Questions

Product-specific technical, compatibility and ordering guidance.

01

Which drives use SDCS-UCM-1C?

The published arrangement applies to DCS880 hardware sizes H1 through H5.

02

How is armature voltage measured?

Two resistor chains reduce the motor-armature voltage before the analog input.

03

Which connectors carry the DC input?

X1 connects to positive C1 and X2 to negative D1.

04

Where does the measurement output connect?

The reduced-voltage signal runs from X3 to XAI analog input AI3.

05

Which positions are used up to 600 V DC?

ABB specifies position 3 at X1 and X2.

06

Why must X1 and X2 be treated as live?

They are at motor DC potential and require converter isolation before service.

07

Which details should be included with an inquiry?

Provide SDCS-UCM-1C 3ADT220090R0008, hardware size, armature voltage, positions, quantity and photos.
