The system provides an output voltage that is directly proportional to thedistance between the probe tip and the observed conductive surface and canmeasure both static (position) and dynamic (vibration) values. The system'sprimary applications are vibration and position measurements on fluid-filmbearing machines, as well as Keyphasor' reference and speed measurements3,

The 3300 XL 8 mm system delivers the most advanced performance in our eddycurrent proximity transducer systems. The standard 3300 XL 8 mm 5-metresystem also fully complies with the American Petroleum Institute's (APl) 670Standard (4th Edition) for mechanical configuration, linear range, accuracy, andtemperature stability. All 3300 XL 8 mm proximity transducer systems providethis level of performance and support complete interchangeability of probes,extension cables, and Proximitor sensors, eliminating the need to match orbench calibrate individual components

Frequently Asked Questions

Q: What is the difference between the 300103 and the 330103 models?
A: The 330103 is a standard forward-threaded probe, while the 300103 features a reverse thread case or specialized counterbore configuration intended for different physical mounting brackets.

Q: What is the standard linear range of this 8mm probe?
A: The standard linear range is 2.0 mm (80 mils), starting from approximately 0.25 mm (10 mils) to 2.25 mm (90 mils) away from the probe tip.

Q: What is the scale factor or sensitivity of this proximity probe system?A4: When matched with a standard 3300 XL 8mm Proximitor, the system has a scale factor of 7.87 V/mm (200 mV/mil).

Q: What does the "-CN" suffix mean for procurement?
A: It means the unit is certified under China Ex (Explosion-proof) standards. When replacing parts in a hazardous zone in China, you must order the "-CN" variant to pass safety audits.

Product Applications

Oil & Gas: Heavy-duty compressors and large centrifugal pumps used in drilling platforms, refineries, and natural gas pipelines.
Power Generation: Monitoring the main shaft operation of steam turbines and generator sets in thermal power plants, nuclear power plants, and hydroelectric power plants.
Hydrocarbon Processing: Monitoring large fans, blowers, and mixing equipment operating continuously in high-temperature, high-pressure, and flammable/explosive environments.
Mining & Industrial: Monitoring bearing displacement and vibration in large mining machinery, steel mill rolling mills, and large rollers in paper mills.
