Brand/Manufature:
Bently NevadaProduct Origin:
USALead Time:
IN STOCKCondition:
Brand New And 100% OriginalCertificate:
CooClaim Your Exclusive Savings – Get in Touch with Sales Manager Lisa Lin Now
: +86-18965423501
: sales7@amikon.cn
:AMKPLC
|
Part Number |
200355-09-00-00 |
|
Mounting Stud ( 09) |
Without mounting stud |
|
Tolerance ( 00) |
100 mV/g ± 5% (10.2 mV/(m/s²) ±5%) |
|
Approval ( 00) |
No certifications required |
|
Sensitivity |
100 mV/g ±20% |
|
Frequency Response Range |
0.5～10,000 Hz (30～600,000 cpm) |
|
Measurement Range |
±50 g (peak value) |
|
Operating Temperature |
-65℉ ～ +250℉ (-54℃ ～ +121℃) |
|
Electrical Interface |
Top outlet 2-pin MIL-C-5015 connector |
|
Mounting Thread Specification |
1/4-28 internal female thread |
The 200350 and 200355 Accelerometers are general purpose, case-mounted seismic transducers designed for use with Trendmaster Pro Constant Current Direct Input Card, part number 149811-02 and the Seismic Direct Input Card, part number 164746-01.
The 200350 and 200355 Accelerometers are contained within a hermetically sealed, stainless steel case. The design provides an extremely rugged transducer, well suited for harsh industrial environments. Each transducer’s top mounted, 2-pin connector (MIL-C5015) allows for easy installation and removal of the interconnecting signal cable. A ¼-28 threaded hole on the bottom of the casing accommodates multiple mounting options.
The 200350 and 200355 Accelerometers contain a piezoelectric sensing device, which generates charge when subjected to vibration. This charge is then converted electronically to a differential voltage signal, which is proportional to the acceleration that is parallel to the sensitive axis of the transducer.
Frequently Asked Questions
Q : What is the base thread type since the "-09" option has no stud?
The base of the sensor housing features an integrated 1/4-28 UNF-2B female threaded hole with a minimum thread depth of 0.210 inches (5.33 mm).
Q : Does this part number include the connecting cable?
No. The 200355-09-00-00 part number covers the transducer body only. Interconnect cables, armored conduits, and mounting hardware must be purchased separately.
Q : What is the mounted resonant frequency of the sensor?
The mounted resonant frequency is 1,250 kcpm (approximately 20.8 kHz). Being well above the 10 kHz operating range prevents mechanical resonance from skewing vibration data.
Q : What is the transverse sensitivity limit?
The transverse (cross-axis) sensitivity is ≤ 5%. This ensures that cross-directional vibrations do not introduce significant error into the primary axis measurement.
Product Applications
Power Generation: Primarily used in thermal power plants, hydropower plants, nuclear power plants, and wind power equipment.
Oil & Gas: Widely used in upstream oil production platforms, oil pipeline pumping stations, large long-distance natural gas compressor units, and centrifugal and reciprocating compressors in liquefied natural gas (LNG) plants.
Petrochemical: Used in refineries and ethylene plants for 24/7 vibration monitoring of high-risk, continuously operating cracked gas compressors, reactor circulating pumps, high-pressure pumps, and mixers to prevent sudden shutdowns.
Metallurgy & Steel: Used for vibration monitoring of blast furnace blowers, oxygen generator compressors, large exhaust fans, rolling mill rotating parts, and heavy-duty gearboxes in steel plants under harsh environments with high temperatures and high dust levels.
